Special Allocators with C++17

I introduced in my last post “Polymorphic Allocators with C++17” the theory of polymorphic allocators in C++17. Today, I will apply the theory.

Before I go on, here are the essential parts of my last post: “Polymorphic Allocators with C++17“.

A Short Reminder

The following program uses polymorphic allocators.

// polymorphicAllocator.cpp

#include <array>
#include <cstddef>
#include <memory_resource>
#include <vector>

int main() {

    std::array<std::byte, 200> buf1;                               // (1)
    std::pmr::monotonic_buffer_resource pool1{buf1.data(), buf1.size()};
    std::pmr::vector<int> myVec1{&pool1};                          // (3)
    for (int i = 0; i < 5; ++i) {
        myVec1.push_back(i);
    }

    char buf2[200] = {};                                           // (2)
    std::pmr::monotonic_buffer_resource pool2{std::data(buf2), std::size(buf2)};
    std::pmr::vector<int> myVec2{&pool2};
    for (int i = 0; i < 200; ++i) {
        myVec2.push_back(i);
    }

}

Now, I want to focus on myVec2. It pushes 200 ints onto the std::pmr::vector<int>. 200 ints do not fit into a char buf[200] and, therefore, std::pmr::new_delete_resource() as the so-called upstream allocator kicks in and calls the global new for the remaining elements. Let me instrumentalize the upstream allocator.

A Tracking Allocator

The following program is based on the previous one, uses a tracking allocator, and makes the dynamic memory allocation and deallocation visible.

// trackAllocator.cpp

#include <array>
#include <cstdlib>
#include <format>
#include <iostream>
#include <memory_resource>
#include <vector>

class TrackAllocator : public std::pmr::memory_resource {
    void* do_allocate(std::size_t bytes, std::size_t alignment) override {
        void* p = std::pmr::new_delete_resource()->allocate(bytes, alignment);
        std::cout << std::format("  do_allocate: {:6} bytes at {}\n", bytes, p);
        return p;
    }

    void do_deallocate(void* p, std::size_t bytes, std::size_t alignment) override {
        std::cout << std::format("  do_deallocate: {:4} bytes at {}\n", bytes, p);
        return std::pmr::new_delete_resource()->deallocate(p, bytes, alignment);
    }

    bool do_is_equal(const std::pmr::memory_resource& other) const noexcept override {
        return std::pmr::new_delete_resource()->is_equal(other);
    }
};


int main() {

    std::cout << '\n';

    TrackAllocator trackAllocator;                         // (1)
    std::pmr::set_default_resource(&trackAllocator);       // (2)

    std::cout << "myVec1\n";

    std::array<std::byte, 200> buf1;
    std::pmr::monotonic_buffer_resource pool1{buf1.data(), buf1.size()};
    std::pmr::vector<int> myVec1{&pool1};                  // (3)
    for (int i = 0; i < 5; ++i) {
        myVec1.push_back(i);
    }

    std::cout << "myVec2\n";

    char buf2[200] = {};
    std::pmr::monotonic_buffer_resource pool2{std::data(buf2), std::size(buf2)};
    std::pmr::vector<int> myVec2{&pool2};                  // (4)
    for (int i = 0; i < 200; ++i) {
        myVec2.push_back(i);
    }

    std::cout << '\n';

}

TrackAllocator is a tracking allocator. It derives from the interface class std::pmr::memory_resource, from which all memory resources derive. TrackAllocator defines the three required member functions do_allocate, do_deallocate, and do_is_equal. Each call forwards its call to std::pmr::new_delete_resource. std:pmr::new_delete_resource is the default memory resource and calls the global new and delete. The member function’s job do_is_equal is to check that the two memory resources are equal. The interesting point in the program is the visualization of the allocation and the deallocation in the member functions do_allocate and do_deallocate.

By instantiating the TrackAllocator (line 1) and make it as the default resource (line 2). myVec1 (line 3) and myVec2 (line 4) use them as the upstream allocator. This allocator kicks in if the primary allocator is consumed. This fallback is not necessary for myVec1, but necessary for myVec2.

This output shows the dynamical allocation and deallocation of myVec2 until all ints fit into the std::pmr::vector<int>.



Rainer D 6 P2 500x500Modernes C++ Mentoring

Be part of my mentoring programs:

  • "Fundamentals for C++ Professionals" (open)
  • "Design Patterns and Architectural Patterns with C++" (open)
  • "C++20: Get the Details" (reopens December 2023)
  • Do you want to stay informed about my mentoring programs: Subscribe via E-Mail.



    You can also bind an upstream allocator to a specific container.

    A Non-Allocating Allocator

    std::pmr::null_resource_allocator is a special allocator. Using this memory resource for allocating causes a std::bad_alloc exception. This memory resource ensures that you do not arbitrarily allocate memory on the heap. Let’s try it out.

    // nullMemoryResource.cpp

    #include <array>
    #include <cstddef>
    #include <iostream>
    #include <memory_resource>
    #include <string>
    #include <vector>

    int main() {

        std::cout << '\n';

        std::array<std::byte, 2000> buf;
        std::pmr::monotonic_buffer_resource pool{buf.data(), buf.size(),  // (1)
                                               std::pmr::null_memory_resource()};
        std::pmr::vector<std::pmr::string> myVec{&pool};                  // (2)
        try {
            for (int i = 0; i < 100; ++i) {                               // (3)
                std::cerr << i << " ";
                myVec.emplace_back("A short string");
            }
        }
        catch (const std::bad_alloc& e) {                                 // (4)
            std::cerr << '\n' << e.what() << '\n';
        }

        std::cout << '\n';

    }


    First, I allocate memory on the stack and initialize std::pmr::monotonic_buffer_resource with it. Then, I use this memory resource and std::pmr::null_memory_resource as an upstream allocator (line 1). In line 2, I create a std::pmr::vector<std::pmr::string>. Because I use a std::pmr::string, the string also uses the memory resource and its upstream allocator. When I use std::pmr::vector<std::string>, std::string allocates using the global new and delete. Finally, in line (3), I create 100 strings and catch in line (4) a std::bad_alloc exception. I got what I deserved. 100 strings will not fit into a std::array<std::byte, 2000> buffer. After 17 strings, the buffer is consumed.

    What’s Next?

    You may have heard it already. The std::pmr::monotonic_buffer has outstanding features. It is pretty fast and does not free memory. I will provide the number in my next post.
