C++ Core Guidelines: Type Safety

The C++ core guidelines support three profiles: type safety, bounds safety, and lifetime safety. Thanks to the guideline support library (GSL), you can check your code against these profiles. Today, I start with the profile type safety.

checklist 1295319 1280

If you don’t know what a profile is, read my last post: C++ Core Guidelines: Profiles. Although the idea of a profile is it to target a specific goal, it needs assistance from the other profiles. This said, the type safety profile needs, for example, assistance from the bounds safety, and lifetime safety profile. Now, let’s dive into the type safety.

Type Safety

Type safety means that you use the types correctly and, therefore, avoid unsafe casts and unions. Type safety consists of eight rules which are called type. The rules start with don’t, always, or avoid and refer to existing rules. If necessary, I will add content to the rules.

Type 1:

  • Don’t use reinterpret_cast

  • Don’t use static_cast for arithmetic types

  • Don’t cast between pointer types where the source type and the target type are the same

  • Don’t cast between pointer types when the conversion could be implicit

The answer to this doesn’t boil down to two points:

Avoid  in particular C-casts and prefer if necessarily named casts:

Avoid casts:

Let’s see what will happen if I screw up the type system.

// casts.cpp





Rainer D 6 P2 500x500Modernes C++ Mentoring

Be part of my mentoring programs:

  • "Fundamentals for C++ Professionals" (open)
  • "Design Patterns and Architectural Patterns with C++" (open)
  • "C++20: Get the Details" (open)
  • "Concurrency with Modern C++" (starts March 2024)
  • Do you want to stay informed: Subscribe.



    #include <iostream>

    int main(){

        double d = 2;
        auto p = (long*)&d;
        auto q = (long long*)&d;
        std::cout << d << ‘ ‘ << *p << ‘ ‘ << *q << ‘\n’;

    }

    Neither the result with the Visual Studio compiler

    castsWin

    nor the result with the GCC or the Clang compiler is promising.

    castsGccClang

    What is so bad about the C-cast? You don’t see which cast is performed. If you use a C-cast, a combination of casts will be applied if necessary. Roughly speaking, a C-cast starts with a static_cast, continues with a const_cast, and finally performs a reinterpret_cast.

    There is another issue I don’t like about a C-cast. It’s challenging to find C-casts in your source code. This remark does not hold for C++ casts such as dynamic_cast, const_cast, static_cast, or reinterpret_cast.

    Of course, you know how I will continue: explicit is better than implicit.

    Prefer named C++-casts

    Including the GSL, C++ offers eight different named casts.

    Here are they including a short description:

    • static_cast: conversion between similar types such as pointer types or numeric types
    • const_cast: adds or removes const or volatile
    • reinterpret_cast: converts between pointers or between integral types and pointers
    • dynamic_ cast: converts between polymorph pointers or references in the same class hierarchy
    • std::move: converts to an rvalue reference
    • std::forward: converts to an rvalue reference
    • gsl::narrow_cast: applies a static_cast
    • gsl::narrow: applies a static_cast

    I know the description is concise. I want to make a least two remarks:

    1. GSL stands for guideline support library and is a header-only library using the namespace gsl.  The GSL can automatically check the rules of the C++ core guidelines and, in particular, the profiles. I will write about this check in a future post. I have already written a post to the GSL: C++ Core Guidelines: The Guidelines Support Library.
    2. What? std::move and std::forward are casts? Let’s have a closer look at the internals of std::move: static_cast<std::remove_reference<decltype(arg)>::type&&>(arg). First, the type of argument arg is determined by decltype(arg). Then all references are removed, and two new references are added. The function std::remove_reference is from the type-traits library. I have already written a few posts to the type-traits library.  In the end, each argument arg to std::move comes out as an rvalue reference.

    Type 2:

    • Don’t use static_cast to downcast

    I can give you a short answer: Use dynamic_cast instead. I have already written about this topic in my post C++ Core Guidelines: Accessing Objects in a Hierarchy.

    Type 3:

    • Don’t use const_cast to cast away const

    Let me be more specific. Casting away const is undefined behavior if the underlying object, such as constInt is not mutable.

    const int constInt = 10;
    const int* pToConstInt = &constInt;

    int* pToInt = const_cast<int*>(pToConstInt);
    *pToInt = 12;          // undefined behaviour


    If you don’t believe me, there is a footnote in the C standard [ISO/IEC 9899:2011] (subclause 6.7.3, paragraph 4) relevant to the C++ standard: The implementation may place a const object that is not volatile in a read-only region of storage. Moreover, the implementation need not allocate storage for such an object if its address is never used.  This means that a modification of an original constant object may have no result.

    Type 4:

    • Don’t use C-style (T)expression or functional T(expression) casts

    The first part of this don’t is relatively easy to answer: prefer named casts such as in type 1.

    The functional T(e) cast is used to construct T from the expression e. Let me show what can happen if you use the functional cast incorrectly.

    // functionalCast.cpp

    void f(int x, long y, double d, long long l){
        char c1(x);
        char c2(y);
        char c3(d);
        char c4(l);
    }

    int main(){
      f(3, 3l, 3.0, 3ll);
    }


    The function f takes four arguments and uses these arguments for initializing char‘s. You get what you deserve and can only hope for a warning. C++ Insights shows explicitly how your code is transformed. A static_cast is applied to each argument.

    cppInsightFunctionalCast

    This process is called narrowing conversion and should be detected by the compiler. Using curly braces instead of round braces checks if a narrowing conversion happens. The C++ compiler must write a warning but typically throws an error when this happens. If you want to be sure that narrowing conversion always triggers an error, treat narrowing warnings with GCC and Clang as an error with -Werror=narrowing. Here is the modified program using curly braces for initialization.

    // functionalCastCurlyBraces.cpp

    void f(int x, long y, double d, long long l){
        char c1{x};
        char c2{y};
        char c3{d};
        char c4{l};
    }

    int main(){
      f(3, 3l, 3.0, 3ll);
    }


    Now, the compiler detects what is going wrong.

    narrowingConversionError

    What’s next?

    In the next post, I will finish the rules to type safety. They are about initialization, unions, and varargs. Now, I have to prepare for a fascinating week in Aurora. I give a two-day concurrency workshop, a back-to-basics talk on concurrency, and a presentation on concepts at the CppCon.
