C++ Core Guidelines: Lifetime Safety And Checking the Rules

The lifetime safety profile in the C++ core guidelines boils down to one issue: don’t dereference a possible invalid pointer. A pointer may be invalid because it is not initialized or the nullptr. A pointer may also point beyond its rage or to a deleted object.

 cemetery




Lifetime Safety

When you don’t dereference a possible invalid pointer, the impact on your program is, according to the C++ core guidelines manifold:
  • eliminates one of the significant sources of nasty errors in C++
  • eliminates a significant source of potential security violations
  • improves performance by eliminating redundant “paranoia” checks
  • increases confidence in the correctness of code
  • avoids undefined behavior by enforcing an essential C++ language rule

Honestly, dealing with pointers is part of a bigger story: ownership. Ownership means that at each point in time, it must be evident who is responsible for managing the lifetime of an object. Roughly speaking, C++11 supports six kinds of ownership:

  • Local objects. The C++ runtime, as the owner, automatically manages the lifetime of these resources. The same holds for global objects or members of a class. The guidelines call them scoped objects.
  • References: I’m not the owner. I only borrowed the resource that cannot be empty.
  • Raw pointers: I’m not the owner. I only borrowed the resource that can be can be empty. I must not delete the resource.
  • std::unique_ptr: I’m the exclusive owner of the resource. I may explicitly release the resource.
  • std::shared_ptr: I share the resource with another shared pointer. I may explicitly release my shared ownership.
  • std::weak_ptr: I’m not the owner of the resource, but I may become temporary the shared owner of the resource by using the method std::weak_ptr::lock.

Compare this fine-grained ownership semantic with a raw pointer. Now you know what I like about modern C++.

You may ask yourself: Having rules is fine, but how can I check that my code follows these rules? Thanks to the Guidelines Support Library (GSL), the rules of the C++ core guidelines can automatically be checked.

Checking the Rules of the Guidelines

The GSL is a small library for supporting the C++ core guidelines. They are already a few implementations of the GSL available.



Rainer D 6 P2 500x500Modernes C++ Mentoring

Be part of my mentoring programs:

  • "Fundamentals for C++ Professionals" (open)
  • "Design Patterns and Architectural Patterns with C++" (open)
  • "C++20: Get the Details" (open)
  • "Concurrency with Modern C++" (starts March 2024)
  • Do you want to stay informed: Subscribe.



    The GSL is a header-only library. Hence, you can use the functions and types of the library quite easily. The best-known implementation is the one from Microsoft, hosted at GitHub: Microsoft/GSL. The Microsoft version requires C++14 support and runs on various platforms. Here are a few quite popular platforms:

    • Windows using Visual Studio 2015
    • Windows using Visual Studio 2017
    • Windows using Visual Studio 2019
    • Windows using Clang/LLVM 3.6
    • Windows using Clang/LLVM 7.0.0
    • Windows using GCC 5.1
    • Windows using Intel C++ Compiler 18.0
    • GNU/Linux using Clang/LLVM 3.6-3.9
    • GNU/Linux using Clang/LLVM 4.0
    • GNU/Linux using Clang/LLVM 5.0
    • GNU/Linux using Clang/LLVM 6.0
    • GNU/Linux using Clang/LLVM 7.0
    • GNU/Linux using GCC 5.1

    Let’s see what I can achieve with the GSL. Here is a program that breaks Type Safety, Bounds Safey, and Lifetime Safety.

    Break of Type Safety, Bounds Safety, and Lifetime Safety

    // gslCheck.cpp

    #include <iostream>

    void f(int* p, int count) {
    }

    void f2(int* p) {
        int x = *p;
    }

    int main() {

        // Break of type safety
        // use of a c-cast
        double d = 2;
        auto p = (long*)&d;
        auto q = (long long*)&d;

        // Break of bounds safety
        // array to pointer decay
        int myArray[100];
        f(myArray, 100);

        // Break of Lifetime Safety
        // a is not valid
        int* a = new int;
        delete a;
        f2(a);

    }




    The comments in the source code document my issues. Let me start Visual Studio 2019 and show my steps to visualize the issues.

    Enable Code Analysis on Build

    EnableCodeAnalysis

    You have to enable the Checkbox. Per default, the three Type Safety, Bounds Safety, and Lifetime Safety rules are not part of the Microsoft Native Recommended Rules.

    Configure your Active Rules

    As you can see from the screenshot, I create my ruleset CheckProfile, consisting of the C++ Core Guidelines Bounds Rules, C++ Core Guidelines Type Rules, and C++ Core Guidelines Lifetime Rules.

     gsl

    Run Code Analysis on Solution

    Applying my set of rules to the code example was quite promising.

    check

    All issues are found. For each issue, such as the first one, I get the line number (17) and the rule of the affected profile (type.4).

    Suppress Warnings

    Sometimes, you want to suppress specific warnings. You can achieve this with attributes. My following example applies two times an array to pointer decay. Only the second call should give a warning.

    // gslCheckSuppress.cpp

    #include <iostream>

    void f(int* p, int count) {
    }

    int main() {

        int myArray[100];

        // Break of bounds safety
        [[gsl::suppress(bounds.3)]] {   // suppress warning
            f(myArray, 100);
        }

        f(myArray, 100);                // warning

    }




    The attribute gsl::suppress(bounds.3) behaves as expected. It’s only valid in its scope. The second break of bounds safety is displayed.

    checkSuppress

    What’s next?

    I skipped the next section of the C++ core guidelines because I already wrote a post to the Guidelines Support Library. The next chapter will be quite controversial: naming and layout rules.
