Types-, Non-Types, and Templates as Template Parameters

I assume you saw the additional keywords typename or template used before a name in a template. Me too. Honestly, I was pretty surprised. Today’s post is about dependent names and various template parameters.



 optical illusion 311130 1280

Before I write about dependent names, I should write about template parameters.

Template Parameter

Template parameters can be types, non-types, and templates.



Rainer D 6 P2 500x500Modernes C++ Mentoring

Be part of my mentoring programs:

  • "Fundamentals for C++ Professionals" (open)
  • "Design Patterns and Architectural Patterns with C++" (open)
  • "C++20: Get the Details" (open)
  • "Concurrency with Modern C++" (starts March 2024)
  • Do you want to stay informed: Subscribe.



    Types

    Okay, types are the most often used template parameters. Here are a few examples:

    std::vector<int> myVec;
    std::map<std::string, int> myMap;
    std::lock_guard<std::mutex> myLockGuard;


    Non-Types

    Non-types can be a

    • lvalue reference
    • nullptr
    • pointer
    • enumerator
    • integral type

    Integrals are the most used non-types. std::array is the typical example because you have to specify at compile time the size of a std::array:

    std::array<int, 3> myArray{1, 2, 3};


    Templates

    Templates can be template parameters. In this case, they are called template parameters. The container adaptors std::stack, std::queue, and std::priority_queue use, per default, a std::deque to hold their arguments, but you can use a different container. Their usage is straightforward.



    std::stack<int> stack1;
    stack1.push(5);

    std::stack<double, std::vector<double>> stack2;
    stack2.push(10.5);




    Their definition may look a little bit weird.



    // templateTemplateParameters.cpp

    #include <iostream>
    #include <list>
    #include <vector>
    #include <string>

    template <typename T, template <typename, typename> class Cont >   // (1)
    class Matrix{
    public:
      explicit Matrix(std::initializer_list<T> inList): data(inList){  // (2)
        for (auto d: data) std::cout << d << " ";
      }
      int getSize() const{
        return data.size();
      }

    private:
      Cont<T, std::allocator<T>> data;                                 // (3)

    };

    int main(){

      std::cout << std::endl;

                                                                        // (4)
      Matrix<int, std::vector> myIntVec{1, 2, 3, 4, 5, 6, 7, 8, 9, 10};
      std::cout << std::endl;
      std::cout << "myIntVec.getSize(): " << myIntVec.getSize() << std::endl;

      std::cout << std::endl;

      Matrix<double, std::vector> myDoubleVec{1.1, 2.2, 3.3, 4.4, 5.5}; // (5)
      std::cout << std::endl;
      std::cout << "myDoubleVec.getSize(): "  << myDoubleVec.getSize() << std::endl;

      std::cout << std::endl;
                                                                        // (6)
      Matrix<std::string, std::list> myStringList{"one", "two", "three", "four"};
      std::cout << std::endl;
      std::cout << "myStringList.getSize(): " << myStringList.getSize() << std::endl;

      std::cout << std::endl;

    }




    Matrix is a simple class template that can be initialized by a std::initializer_list (line 2). A Matrix can be used with a std::vector (line 4 and line 5) or a std::list (line 6) to hold its values. So far, nothing special.

    templateTemplateParameters

    But hold, I forget to mention lines 1 and line 3. Line 1 declares a class template that has two template parameters. Okay, the first parameter is the type of the elements, and the second parameter stands for the container. Look at the second parameter: template <typename, typename> class Cont >. This means the second template argument should be a template requiring two template parameters. The first template parameter is the type of elements the container stores, and the second is the defaulted allocator a container of the standard template library has. Even the allocator has a default value, such as in the case of a std::vector. The allocator depends on the type of elements.

    template<
        class T,
        class Allocator = std::allocator<T>
    > class vector;




    Line 3 shows the usage of the allocator in this internally used container. The matrix can use all containers, which are of the kind: container< type of the elements, allocator of the elements>. This is true for the sequence containers such as std::vector, std::deque, or std::liststd::array and std::forward_list would fail because std::array needs an additional non-type for specifying its size at compile-time, and std::forward_list does not support the size method.

    Preparation done. Now, I can write about dependent names.

    Dependent Names

    First of all. What is a dependent name? A dependent name is essentially a name that depends on a template parameter. Let me show what that means. Here are a few examples based on cppreference.com:



    template<typename T>
    struct X : B<T> // "B<T>" is dependent on T
    {
        typename T::A* pa; // "T::A" is dependent on T
        void f(B<T>* pb) {
            static int i = B<T>::i; // "B<T>::i" is dependent on T
            pb->j++; // "pb->j" is dependent on T
        }
    };




    Now, the fun starts. A dependent name can be a type, a non-type, or a template parameter. The name lookup is the first difference between non-dependent and dependent names.

    • Non-dependent names are looked up at the point of the template definition.
    • Dependent names are looked up when the template arguments are known. This means at the point of template instantiation.

    If you use a dependent name in a template declaration or template definition, the compiler has no idea whether this name refers to a type, a non-type, or a template parameter. In this case, the compiler assumes that the dependent name refers to a non-type, which may be wrong. This is the case in which you have to help the compiler.

    Before I show you two examples, I must add an exception to this rule. You can skip my following few words if you want to get a general idea and jump directly to the following subsection. The exception is: if the name refers in the template definition to the current instantiation, the compiler can deduce the name at the point of the template definition. Here are a few examples:



    template <class T> class A {
        A* p1;    // A is the current instantiation
        A<T>* p2; // A<T> is the current instantiation
        ::A<T>* p4; // ::A<T> is the current instantiation
        A<T*> p3; // A<T*> is not the current instantiation
    };
    template <class T> class A<T*> {
        A<T*>* p1;  // A<T*> is the current instantiation
        A<T>* p2;   // A<T> is not the current instantiation
    };
    template <int I> struct B {
        static const int my_I = I;
        static const int my_I2 = I+0;
        static const int my_I3 = my_I;
        B<my_I>* b3;  // B<my_I> is the current instantiation
        B<my_I2>* b4; // B<my_I2> is not the current instantiation
        B<my_I3>* b5; // B<my_I3> is the current instantiation
    };




    Finally, I came to the critical idea of my post. If a dependent name could be a type, a non-type, or a template, you have to give the compiler a hint.

    Use typename if the Dependent Name is a Type

    After such a long introduction, the following program snippet makes it pretty clear.



    template <typename T>
    void test(){
        std::vector<T>::const_iterator* p1;          // (1)
        typename std::vector<T>::const_iterator* p2; // (2)
    }




    Without the typename keyword in line 2, the name std::vector<T>::const_iterator in line 2 would be interpreted as a non-type and, consequently, the * stands for multiplication and not for a pointer declaration. Exactly this is happening in line (1).

    Similarly, if your dependent name should be a template, you have to give the compiler a hint.

    Use .template if the Dependent Name is a Template

    Honestly, this syntax looks a little bit weird.



    template<typename T>
    struct S{
        template <typename U> void func(){}
    }
    template<typename T>
    void func2(){
        S<T> s;
        s.func<T>();             // (1)
        s.template func<T>();    // (2)
    }




    Same story as before. Compare lines 1 and 2. When the compiler reads the name s.func (line 1), it interprets it as non-type. This means the < sign stands for the comparison operator but not opening the square bracket of the template argument of the generic method func. In this case, you must specify that s.func is a template, such as in line 2: s.template func

    Here is the essence of this post in one sentence: When you have a dependent name, use typename to specify that it is a type or .template to specify that it is a template.

    What’s next?

    The following rules in the C++ Core Guidelines are C-style programming and source files. Let’s see in my next post what this means.
